H300 Series Economic Frequency Inverter

Name: H300 Series Economic Frequency Inverter
SKU: 0

H300 series frequency inverter is a compact economic design frequency inverter and can also be used as solar pump inverter. It is with small body to save installation space and removable keypad that is easy to use. It can meet many application requirements of different fields. It is used to drive various automation production equipment involving textile, paper-making, machine tool, packing, food, fan and pump.

Email : info@fmz-industry.com

WhatsApp : +86 15921436186

Product Details

Specification

Single-phase 220V (-15%~15%) 0.4-5.5KWThree-phase 380V (-15%~+15%) 0.4-11KW

H300 – 2R2G /3 R0P - T4

No.	Sign	Description	Remarks
①	H300	Product Series	H300: Without RS485& Braking Unit H300A: With RS485& Braking Unit
②	2R2G	Power range + Load type	2R2G: 2.2kW; G: Heavy Load
③	3R0P	Power range + Load type	3R0P: 3.0kW; P: Light Load
④	T4	Voltage	S2: AC 220V(-15%)-220(+15%) 1PH Input & 3PH Output T2: AC 220V(-15%)-220(+15%) 3PH Input & 3PH Output T4: AC 380V(-15%)-380(+15%) 3PH Input & 3PH Output

Product features:

(1)V/f & Vector control

(2)Save space

(3)Optional RS485 communication(4)Easy to operate

(5)Removable keypad

(6)Din-rail Installation Design

(7)220V 1-Phase To 3-Phase Up To 5.5kW

(8)220V 3-Phase To 3-Phase Up To 5.5kW

Model Selection Table

Model	Rated Power (KW)	Rated Input Current (A)	Outline Dimension(mm)	Package Dimension(mm)	G.W (KG)
Single-phase 220V, 50/60 Hz
H300-0R4G-S2	0.4	2.1	17079127	202111157	1.0
H300-0R7G-S2	0.75	3.8			1.0
H300-1R5G-S2	1.5	7.0			1.0
H300-2R2G-S2	2.2	9.0	18786144	215119166	1.2
H300-3R0G-S2	3.0	13	216101151	248137180	1.7
H300-4R0GS-S2	4.0	15	216101151	248137180	1.7
H300-4R0G-S2	4.0	15	23711168	262164205	2.4
H300-5R5G-S2	5.5	20	23711168	262164205	2.4
Three-phase 380V, 50/60 Hz
H300-0R4G-T4	0.4	1.5	17079127	202111157	1.0
H300-0R7G-T4	0.75	2.1			1.0
H300-1R5G-T4	1.5	3.8			1.0
H300-2R2GS-T4	2.2	5.1			1.0
H300-2R2G-T4	2.2	5.1	18786144	215119166	1.2
H300-3R0G-T4	3.0	7.1	18786144	215119166	1.2
H300-4R0G-T4	4.0	9.0	216101151	248137180	1.7
H300-5R5G-T4	5.5	12.6	216101151	248137180	1.7
H300-7R5G-T4	7.5	16.1	237111168	262164205	2.4
H300-11RG-T4	11	25	249143172	310205245	3.5
